The 101 Integrated Amplifier is the latest integrated amplifier in the Burmester product range and a supreme example for the perfect combination of efficient class D power sections and an analogue power supply. With its power reserves thus made available the 101 easily achieves in a compact design the warm and well-balanced sound which is known to be a trademark of the Burmester tone. The switchable „Smooth“ function produces a rounded and detailed sound image even with low volume levels.

OVERVIEW

Within the Burmester sound world the 101 integrated amplifier commends itself as a perfect game partner for the 102 CD player, notably when combined with the loudspeakers from the Burmester portfolio. The additional balanced outputs also allow to use it as a dedicated preamp or upgrade it with external power amps at a later time.

FEATURES

As you would expect it from Burmester, the 101 also features a balanced circuit layout. Pre-Out and headphone amplifier are DC-coupled, meaning they dispense entirely with distorting coupling capacitors in the signal path.

• Pre-amp output
• High damping factor enables effortless control of any speaker over the full frequency range
• Head phone jack (at the front)
• Stable at any load over the entire frequency range
• Balanced circuit layout
• Switchable „Smooth“ function
• A built-in protective circuit outside of the signal path monitors the 101 during operation with regard to overheating, DC offset and overloading
• Massive binding posts for speaker cables (best performance with spade lugs!)
• Display on/off
• BurLink with RS-232 (optional)



SPECIFICATIONS



• Stereo output per channel into 4 Ω: 120 W
• Inputs: 3 XLR, 2 RCA
• Input Impedance XLR/RCA: 16,4 kΩ / 8,2 kΩ
• Input Sensitivity 1% THD + N, 4 Ω: 550 mV
• Frequency Response -3dB: 5 Hz – 60 kHz
• THD + N: 0,015 %
• Damping Factor: 250
• Signal-to-noise: > 92 dB
• Gain: variable
• Pre-Out: balanced
• Tone control (can be bypassed): -
• Headphone jack: 6.3 mm
• Remote controlled: yes
• Weight: 12 kg (26,7 lbs)
• Width: 482 mm (19”) x Height: 93 mm (3,7”) x Depth (without plugs and circuit points): 350 mm (13,8”)
